Toffee Candy Production Line
|
Toffee Candy Production
Line
Use: central filled soft toffee.
Model: CTNYQYH150/300/450/600
Capacity: 150/300/450/600 kg/hr |
|
Product Description
|
|
|
Product
Description:
CTNYQYHGS series toffee candy production line is
one of the main products of YIYUAN MACHINERY. It was
introduced and developed according to the demands of
the customer.
This line is mainly composed of sugar dissloving
tank, storage tank., specially toffee candy cooking,
automatic depositing machine and cooling tunnel etc.
The strongpoint of the line is as following:
* PLC /computer process control available;
* An LED touch panel for easy operating;
* The production capacity from 150 kgs/h to
450kgs/h;
* Optional (mass) flowing controlled by Frequency
inverters ;
* In-line injection, dosing and pre-mixing
techniques for the proportional addition of
liquid(milk); Dosing pumps for the automatic
injection of colors, flavors and acids;.
* Moulds can be made according to the candies
samples provided by the customer.
|
|
Function:
|
|
|
Used in the
production of toffee candy, sandwiching soft
milk candy. |
|
Parameters
|
|
|
Model |
CTNYQYH150 |
CTNYQYH300 |
CTNYQYH450 |
CTNYQYH600 |
|
Capacity |
150kg/h |
300kg/h |
450kg/h |
600kg/h |
|
Max Candy Weight |
6g |
6g |
6g |
6g |
|
Depositing Speed |
55-65n/min |
55-65n/min |
55-65n/min |
55-65n/min |
|
Steam Requirement |
250kg/h, 0.5-0.8MPa |
300kg/h,0.5-0.8MPa |
400kg/h, 0.5-0.8MPa |
500kg/h, 0.5-0.8MPa |
|
Compressed Air Requirement |
0.2m3/min,
0.4-0.6MPa |
0.2 m3/min,
0.4-0.6MPa |
0.25 m3/min,
0.4-0.6MPa |
0.25 m3/min,
0.4-0.6MPa |
|
Working Condition |
(Temp)20-25°C（Humidity）55% |
(Temp)20-25°C（Humidity）55% |
(Temp)20-25°C（Humidity）55% |
(Temp)20-25°C（Humidity）55% |
|
Electric Power Needed |
32Kw/380V |
39 Kw/380V |
48 Kw/380V |
75 Kw/380V |
|
Total Length |
17m |
17m |
18m |
18m |
|
Gross Weight |
3500kg |
4000kg |
4500kg |
5000kg |
|
|
