Cereal color sorter
CE6 Cereal Color Sorter
|
Name |
CE6 |
|
Type |
6SXZ-240E-CK |
|
Channels |
240 |
|
Throughput£¨t/h£© |
<5.0 |
|
Sorting accuracy£¨%£© |
>99 |
|
Contaminant Reject Ratio£¨%£© |
>95 |
|
Optimized carryover (bad
:good) |
>8:1 |
|
Channels preset for primary
sorting and re-sorting |
160:80 |
|
Voltage (V) |
~220(50Hz) |
|
Power of main machine (kW) |
2.9 |
|
Air Pressure (MPa) |
>0.4 |
|
Air consumption (m3/min) |
<3.0 |
|
Weight (Kg) |
800 |
|
Dimension (L¡ÁW¡ÁH)£¨mm£© |
2025¡Á1395¡Á1875 |
SS-B_A-CK Intelligentized Color
Sorter
¡¡
|
Type |
SS-B120A-CK |
|
Channels |
120 |
|
Output (t/h) |
4.0~5.0 |
|
Sorting accuracy |
>99.9% |
|
Optimized carryover (bad
:good) |
>8: 1 |
|
Channels preset for primary
and secondary sorting |
90:30 |
|
Voltage (V) |
~220V/ 50Hz |
|
Power of main machine (kw) |
0.9 |
|
Power of heater (kw) |
1.2 |
|
Pressure at air source (MPa) |
¡Ý0.6 |
|
Air consumption (L/min) |
600~1500 |
|
Weight (Kg) |
900 |
|
Dimension (L¡ÁW¡ÁH) |
1875¡Á1108¡Á1936 |
SS-L_C/D-CK CCD Belt-Type Color
Sorter
|
Type |
SS-L40C/D-CK |
SS-L60C/D-CK |
|
Channels |
40 |
60 |
|
Output (t/h) |
¡Ü3.0 |
¡Ü5.0 |
|
Sorting accuracy
|
>99.6% |
>99.6% |
Optimized carryover
(first blow-off bad :good )
|
1:3 |
1:3 |
|
Voltage (V) |
~380V/50Hz |
~380V/50Hz |
|
Power of main machine (kw)
|
1.8 |
2.0 |
|
Pressure at air source (MPa)
|
0.6-0.8 |
0.6-0.8 |
|
Air consumption (m3/min)
|
¡Ü1.8 |
¡Ü2.2 |
|
Weight (Kg) |
800 |
900 |
|
Dimension (L¡ÁW¡ÁH)
|
2660¡Á1020¡Á1852 |
2660¡Á1320¡Á1852 |
Note: All the performance index
listed above has been referred to
horsebean (2% of contaminant), and
the specific index is to be altered
subject to the content of
contaminants.
