Uses:
It
applies in drying,
sterilizing and heat
treatment of articles under
the vacuum condition in
laboratories of industrial
mining enterprise, colleges
and universities and
scientific research
institute etc.
Characteristics:
1. The
rectangular workroom makes
full use of effective
volume. The intellectual
temperature controller.
2.
Double-layer tempering
bulletproof glass door is
easy to observe the
articles in the workroom.
3. The
closed door could be
adjusted. The complete
formed high temperature
resistance silicon rubber
door-sealing ring could
guarantee the high vacuum
degree.
4. The
workroom adopts cold-rolled
steel plate or stainless
steel plate. It is durable.
|
reference |
¡¡ |
¡¡ |
¡¡ |
|
type |
DZF-1 |
DZF-2 |
DZF-3 |
|
voltage£¨V£© |
220V/50Hz |
220V/50Hz |
220V/50Hz |
|
power
(KW) |
0.3 |
1.2 |
1.4 |
|
range
of temperature(¡æ) |
50-250 |
50-250 |
50-250 |
|
tolerance of
temperature(¡æ) |
¡Ü1 |
¡Ü1 |
¡Ü1 |
|
size
of workroom(mm) |
300x300x275 |
415x345x370 |
450x450x450 |
|
vaccum degree(Pa) |
£¼133 |
£¼133 |
£¼133 |
¡¡ |
