Solid-Ink Coding Machine-TMY-380F
¡¡



TMY-380F                                                        TMY-380F/W


Product Description

Adopt photoelectric mechanism technology, automatic temperature control, auto counting, adjustable print position.
Adopt solid-ink coding, legible printing, fast dry, and color selectable, not easy to remove.
With multi function print wheel suitable for R type and T type arrangement.
Fit for printing on paper, plastic film and aluminum foil.
Automatic high speed, high efficiency, up to 300pcs per minute.

Specifications

TMY-380F

TMY-380F/W

Voltage(V/Hz)

AC 220/50  110/60

Power(W)

180

Solid Ink Roller(mm)

35¡Á32   35¡Á16

Printing Speed(pcs(/min)

¡Ü300

Object Size(mm)

L:50-500 W:30-190

L:50-550 W:30-300

Max. Printing Line

T Type(10.5PT):11Lines (Max.10 characters/line)
R Type(10.5PT):8Lines(Max.8 characters/line)

Printing Size(mm)

Within 60-250

Type Size(mm)

2¡Á1.5( 8PT )  2.5¡Á2(9PT)  3¡Á3(10.5PT)  4¡Á2.5(18PT)

Dimension (L¡ÁW¡ÁH)(mm)

440¡Á345¡Á300

440¡Á465¡Á300

Net Weigh(Kg)

23

26



Impress or Solid-Ink Coding Machine-TMY-300A
¡¡

¡¡



TMY-300A                                                                    TMY-420A


Product Description

The machine is suitable for printing labels on the face of papers, tissue paper, non-ferrous, plastic film and aluminum film. It adopts solid-ink coding and also by embossing printing; whatever adopting solid-ink coding, it has the features of instant printing and instant drying, and strong adhesion; the character from the embossing wheel is clear and widely used for all kinds of thickness of object printed.
The machine can print by embossing wheel without heating system is available for customizing.

Specifications

TMY-300A

TMY-420A

Voltage(V/Hz)

AC 220/50 110/60

Power(W)

230

Object Size(mm)

L: 60-600  W:50-300

L: 60-600  W:50-420

Printing Speed(pcs/min)

¡Ü 300

Object Thickness(mm)

0.05-3.0

Printing Type

Impress or Solid ink

Type Size(mm)

2¡Á1.5(8PT)  2.5¡Á2(9PT)  3¡Á3(10.5PT)  4¡Á2.5(18PT )

Dimension (L¡ÁW¡ÁH)(mm)

430¡Á445¡Á310

430¡Á565¡Á310

Net Weigh(kg)

30

34



Lock-And-Follow Solid-Ink Coding Machine-TMY-812
¡¡



TMY-812G                                                    TMY-812A


Product Description

• The machine can be used to math with vertical and horizontal automatic packaging machine, and print the label of the product.
•  It can print by solid-ink roller; the character is clear, instant printing and instant dry, with strong adhesion.
•  It can list 10 characters one line, at most 11lines.MY-821A with motor driving.
•  The print location of photo electricity tracing can be adjustable, with accuracy.

Specifications

TMY-812G

TMY-812A

Voltage(V/Hz)

AC 220/50  110/60

Power(W)

130

150

Max. Printing Speed(pcs/min)

300

Max. Printing Line

T Type(10.5PT):11Lines Max.10Pcs/Line)
R Type(10.5PT):8Lines (Max.8Pcs/Line)

Size of Character(Height)(mm)

2¡Á1.5(8PT) 2.5¡Á2(9PT) 3¡Á3(10.5PT)

Size of Color Ribbon or Solid-ink Roller(mm)

§æ35¡Á32

Max. Horizontal Adjustable Size for Printer

150 (Confirm When Ordering)

Weight for Printer (Without Stand)(kg)

4

Max. Film Width (mm)

400 500 600



Lock-And-Follow Color Ribbon Printing Machine-THP-241G
¡¡

THP-241G


Product Description

•  The machine can be used to math with vertical and horizontal automatic packaging machine, and print the label of the product.
•  THP-241G print by color ribbon, the character is clear, instant printing and instant dry, with strong adhesion.
•  THP-241G can list 15 words of the one line, at most 3 lines.
•  The print location of photo electricity tracing can be adjustable, with accuracy.

Specifications

THP-241G

Voltage(V/Hz)

AC 220/50  110/60

Power(W)

135

Max. Printing Speed(pcs/min)

200

Max. Printing Line

2¡Á3¡Á15mm:3 Lines (Max. 15 Pcs/Line)

Size of Character(Height)(mm)

3.0

Size of Color Ribbon or Solid-ink Roller(mm)

25 30 35 (Width)

Max. Horizontal Adjustable Size for Printer

150 (Confirm When Ordering)

Weight for Printer (Without Sand)(kg)

7

Max. Film Width (mm)

400 500 600


Color Ribbon Hot Printing Machine-THP-280
¡¡

¡¡

THP-280


Product Description

•  Adopt color ribbon, has the features of clear printing, easy dry, non sticky, not easy to wipe off.
•  Can print codes on thin paper cardboard, paper sheet, leather, plastic film, aluminum foil, especially fit for coding on paper box of shoes, clothing.
•  Adopt constant temperature controlling and adjustable temperature, printed suitable for color ribbon made out of different kinds of materials.

•  It can automatic continuously print codes or control by pedal.

Specifications

THP-280

Voltage(V/Hz)

AC 220/50 110/60

Power(W)

120

Printing Speed(pcs/min)

0-100

Printing Quantity

One Line

2¡Á4 Max.15 characters

Two Lines

2¡Á4 Max.30 characters

Three Lines

2¡Á4 Max.45 characters

Color Ribbon Width(mm)

25 30 35

Dimension(L¡ÁW¡ÁH)(mm)

255¡Á225¡Á325

Net Weight (Kg)

9.5



Color Ribbon Hot Printing Machine-TDY Series
¡¡

¡¡



TDY-8                                                                  TDY-6


Product Description

•  Adopt color ribbon, has the features of clear printing, easy dry, non sticky, not easy to wipe off.
•  Can print codes on thin paper cardboard, paper sheet, leather, plastic film, aluminum foil, especially fit for coding on paper box of shoes, clothing.
•  Adopt constant temperature controlling and adjustable temperature, printed suitable for color ribbon made out of different kinds of materials.
•  It is very simple and easy to use.

Specifications

TDY-8

TDY-6

Voltage(V/Hz)

AC 220/50 110/60

Power(W)

40

Printing Speed(pcs/min)

0-100

Printing Quantity

One Line

2¡Á4Max.15 characters

3¡Á5 Max.6 characters

Two Line

2¡Á4Max.30characters

3¡Á5 Max.10 characters

Three Lines

2¡Á4Max.45characters

-

Color Ribbon Width(mm)

25 30 35

30

Dimension(L¡ÁW¡ÁH)(mm)

270¡Á160¡Á220

280¡Á160¡Á220

Net Weight (Kg)

2

2.1



Ink Inject Printer-THLIJ-2000C
¡¡



TMP-58                                                         THLIJ-2000C


Product Description

THLIJ -2000C INK INJECT PRINTER can print up to three lines of fonts and be integrated into high-speed production lines. Its functions and performance have reached that of international standards of the same category. Automatic ink viscosity measuring and control, fault alarm indicator and automatic hydraulic system cleaning can combine to ensure the continuous stable operation of this system.

THLIJ -2000C is capable of creating a wide range of graphics, languages, numbers and characters. Users can select different high-quality and high-speed printing modes according to their own needs. The RS232 portal provides THLIJ -2000C with the access to a computer or network by means of GUOMEI software.

Specifications

THLIJ -2000C

Voltage (V/Hz)

AC 220/50 110/60

Lattice Size(mm)

7¡Á5, 7¡Á9,10¡Á7,16¡Á16,16¡Á24,24¡Á24

Print Lines

Max. 3 (7¡Á5)

Letter Height (mm)

1.2-12

Spray Speed

2000characters/sencod(7¡Á5 single line)

Dimension(L¡ÁW¡ÁH)(mm)

400¡Á240¡Á510

Net Weight(kg)

33

¡¡

¡¡
